Suzhou, China – August 28, 2023 – Suzhou Qunzhi NC Company is eagerly preparing to make its mark at Hannover EMO 2023, one of the world's premier trade fairs for the metalworking industry. The company will be proudly demonstrating its VL8B Vertical Machine Center at the event.
With less than a month to go before the exhibition kicks off, the buzz around Suzhou Qunzhi's booth in Hall 13, Booth A18, is already palpable. The international department has been delighted to receive a surge of interest from prospective visitors and clients, all eager to explore the possibilities of cooperation.
Suzhou Qunzhi extends a warm and enthusiastic welcome to friends, clients, and industry peers to visit their booth. The VL8B Vertical Machine Center promises to be a highlight, showcasing the company's commitment to cutting-edge technology and precision machining solutions.
The anticipation is building, and the team at Suzhou Qunzhi is gearing up to engage in face-to-face meetings, share insights, and explore collaborative opportunities with the global community of industry professionals.
Hannover EMO 2023 is set to be an exciting and fruitful event, and Suzhou Qunzhi can't wait to be a part of it. Stay tuned for more updates as the exhibition draws near, and be sure to mark your calendar to visit Suzhou Qunzhi at Hall 13, Booth A18.
Machine Model | VL8B | |
Travel | Three-axis travel X/Y/Z | 800/550/550 |
Spindle face to table surface | 120-700 | |
Spindle center to column guide surface | 600 | |
Workbench | Table size | 1000*550 |
Maximum load capacity | 500kg | |
T-slots (number of slots * width * spacing) | 5*18*100 | |
Spindle | Taper | BT40 |
Spindle rotational speed | 10000rpm | |
Spindle rivet | 45° | |
Main motor | 11-15KW | |
travel speed | X\Y axis rapid traverse speed | 48M/min |
Z-axis rapid traverse speed | 48M/min | |
Three-axis cutting feed rate | 1-10000mm/min | |
X-axis rail | 35-Roller-4 Slider | |
Y-axis line rail | 45-Roller-4 Slider | |
Z-axis line rail | 45-Roller-6 Slider | |
Triple Axis Screws | Φ40-P16 | |
Precision | Position accuracy | ±0.004/300 |
Repeat Positioning Accuracy | ±0.003 | |
Tool magazine | Number of tools | 24. |
Knife Selection Form | arbitrary | |
Maximum tool length | 300mm | |
Maximum tool weight | 8kg | |
Maximum tool diameter | φ80 (full blade) φ150 (neighboring blade) | |
Automatic tool change time | 1.55s (neighboring tool) | |
pneumatic | 0.65MPa | |
Cool down | cooling power | 1000W |
Lift | 30M | |
Flow | 4 cubic meters/hour | |
Coolant capacity | 280L | |
Other | Weight | 6500kg |
Machine Size | 2600*2850*2800 | |
power supply | AC380V 3PH, 50Hz | |
total power | 20KW | |
